BOEING B787-8

Make an Offer

  • YEAR OF MANUFACTURE

    2010

  • HOURS

    1'741

  • CYCLES

    881

  • PASSENGERS

    80

FLOOR PLAN

Floorplan

Highlights

  • Presidential Office

  • Bedroom & Lavatory with Shower

  • FAA Compliant

  • Low hours

  • Airstair

  • Long range 7500nm

  • Overhead Flight Crew Rest & Overhead Flight Attendant Rest

specifications

  • ENGINES

    Provided by
    GE - MODEL GENX-1B70/75/P2
    Serial Numbers
    L#956294 & R#956296
  • APU

    Provided by
    HAMILTON SUNDSTRAND - MODEL APS5000A
    Serial Number
    HSC-E1425292
  • INTERIOR

    Cabin Completion Date
    January 2016
    Crew rest
    OFCR & OFAR
    Entertainment / Connectivity / Equipment
    Full IFE/CMS installed Satcom and Wifi
    Galley Equipment
    Forward & Afterward Fully equipped
    Lavatory
    8 + 1 VVIP
    Monitors
    7 EA 42” monitors & 87 EA 11” monitors
    Luggage/cargo
    Fwd cargo max load 19,050kg / Aft cargo max load 16,093kg / Bulk cargo 2,735kg
  • EXTERIOR

    Last painted
    2014
    Base paint color(s)
    White
    Stripe color(s)
    Green & Red
  • NAVIGATION COMPLIANCE

    RVSM MNPS PRNAV FANS 1A CPDLC ADS-B Out TCAS 7.1 RNP

AVIONICS

  • EFIS (ELECTRONIC FLIGHT INSTRUMENT SYSTEM)

  • ESIS (ELECTRONIC STANDBY INSTRUMENT SYSTEM)

  • FMS (FLIGHT MANAGEMENT SYSTEM)

  • GPS (GLOBAL POSITIONING SYSTEM): SINGLE

  • DCMF (DATA COMMUNICATION MANAGEMENT FUNCTION): SINGLE

  • CDU (CONTROL DISPLAY UNIT)

  • ADC (AIR DATA COMPUTER)

  • NAV (INTEGRATED NAVIGATION RADIO): DUAL, HONEYWELL

  • RMI (RADIO MAGNETIC INDICATOR)

  • DME (DISTANCE MEASURING EQUIPMENT): DUAL, HONEYWELL

  • HUD (HEAD UP DISPLAY): DUAL, COLLINS

  • ADF (AUTOMATIC DIRECTION FINDER): DUAL, HONEYWELL

  • AFCS (AUTO FLIGHT CONTROL SYSTEM)

  • A/P (AUTOPILOT)

  • SELCAL (SELECTIVE CALLING SYSTEM): SINGLE

  • VHF COM (VERY HIGH FREQ. COMMUNICATION): TRIPLE, COLLINS

  • HF COM (HIGH FREQ. COMMUNICATIONS): DUAL, COLLINS

  • SATCOM (SATELLITE COMMUNICATIONS): SINGLE, COLLINS

  • RADAR: DUAL, COLLINS

  • RADAR ALT (RADAR ALTIMETER)

  • XPNDR (TRANSPONDER)

  • GPWS (GROUND PROXIMITY WARNING SYSTEM): SINGLE

  • TCAS (TRAFFIC COLLISION AVOIDANCE SYSTEM): DUAL, COLLINS

  • ELT (EMERGENCY LOCATOR TRANSMITTER): SINGLE, HONEYWELL

  • CVR (COCKPIT VOICE RECORDER): DUAL, COLLINS

  • DFDR (FLIGHT DATA RECORDER)

  • VOR; DUAL, HONEYWELL

  • ILS, DUAL, HONEYWELL

  • ISS, DUAL, COLLINS

  • RRA (RADIO ALTIMETER); DUAL, HONEYWELL

Range map
